Description
The Snorkel S3219E electric scissor lift packs big features in a compact size. Easily driven through a standard doorway, this scissor lift suits indoor and outdoor applications. A telescopic roll-out deck extension maximizes platform space and deep cycle batteries maximize working hours.
Specifications
Manufacturer
Snorkel
Year
2025
Model
S3219E
Category
Material Handling Equipment
Subcategory
Scissor Lifts
Overall width
0.81m
Max platform height
5.79m
Stowed height
2.11m
Overall length (with step)
1.78m
Overall length (without step)
1.73m
Weight
1,438kg
Platform capacity (SWL)
250kg
Max wind speed
12.5m/s
Max drive speed (elevated)
0.6km/h
Max drive speed (stowed)
3.2km/h
Raise / lower time
20 / 38 seconds
Gradeability
25%
Tires
12 x 4 non-marking rubber
Controls
proportional
Drive system
2 wheel drive
Power source
24V DC battery electric
Max working height
7.79m
Ground clearance (stowed)
66mm
Ground clearance (elevated)
19mm
Max drive height
5.79m
Inside turning radius
0.1m
Outside turning radius
1.63m
Charger
90 - 240V, 25amp
Min height (guardrails folded)
1.65m
Platform size (stowed)
0.72m x 1.62m
Platform size (extended)
0.72m x 2.53m
Deck extension length
0.91m
