Description
The Snorkel TB86J telescopic boom lift delivers precise reach. The TB86J balances compact dimensions and high reach for full versatility on the jobsite. An added jib offers flexibility and even more outreach where needed most.
Specifications
Manufacturer
Snorkel
Model
TB86J
Year
2024
Category
Material Handling Equipment
Subcategory
Boom Lifts
Overall width
2.6m
Overall length
12.9m
Weight
17,549kg
Max working height
28.2m
Max platform height
26.2m
Max horizontal reach
23.9m
Platform size
2.44m x 0.91m
Stowed height
3.0m
Ground clearance
330mm
Platform capacity (SWL)
227kg
Max drive height
26.2m
Max wind speed
12.5m/s
Max drive speed (elevated)
1.0km/h
Max drive speed (stowed)
4.8km/h
Raise / lower time
70/65 sec
Jib length
1.67m
Jib arc
135° (+70°/-65°)
Superstructure rotation
360°
Inside turning radius
2.4m
Outside turning radius
4.7m
Tires
15 x 625 foam filled lug
Controls
proportional joystick
Drive system
4 wheel drive
Power source
Kubota V2403 48kW/59hp diesel - Tier 4 Final
Tailswing
1.9m
