Description
The Snorkel 600S All Terrain telescopic boom lift is fitted with four independent rubber tracks. Easily tackling soft and sensitive environments, this boom lift offers superb maneuverability without sinking or disturbing the ground. Developed with a high torque hydraulic pump, it also has excellent gradeability and can climb gradients up to 45%.
Specifications
Manufacturer
Snorkel
Model
600S-All-Terrain
Year
2023
Category
Material Handling Equipment
Subcategory
Boom Lifts
Max working height
20.5m
Max platform height
18.5m
Overall length
9.2m
Overall width
2.46m
Stowed height
2.61m
Max drive height
18.5m
Platform size
2.44m x 0.91m
Transport Length
9.2m
Transport Height
2.61m
ground clearance
444mm
Weight
13,027kg
Max wind speed
12.5m/s
Max drive speed (elevated)
0.96km/h
Max drive speed (stowed)
5.6 km/h
Raise / lower time
50 / 50 seconds
Gradeability
45%
Inside turning radius
5.94m
Outside turning radius
8.38m
Tires
Independent rubber tracks
Controls
proportional drive, raise, slew, extend, jib and platform rotate
Drive system
4 track drive
Power source
Deutz 2.9L 55kW/74hp - Stage V
Platform capacity - unrestricted
272kg
Platform capacity - restricted
454kg
Superstructure rotation
360° continuous
Tailswing
1.2m
